Omron D2MC-01F, Rotary Micro Switch, Tab Terminal, 500 mA @ 30 V dc, SPDT, IP40

Name: Omron D2MC-01F, Rotary Micro Switch, Tab Terminal, 500 mA @ 30 V dc, SPDT, IP40
Brand: OMRON
SKU: D2MC-01F
Availability: OutOfStock

Part Number : D2MC-01F

Availability: Sold out

Detailed Description
Specifications
Downloads

Omron D2MC Low-torque Basic Switch

Highly Reliable Rotary-action Switch for Low Torque Operation
0.5-A rated model employs crossbar gold-alloy contacts for excellent contact reliability in the micro load range.
Long life (10,000,000 mechanical operations min.) through use of a movable coil spring.

Brand	Omron
Actuator Type	Rotary
Terminal Type	Tab
Contact Current Rating	500 mA @ 30 V dc
Contact Configuration	SPDT
IP Rating	IP40
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+80°C
Contact Material	Gold Alloy
Mechanical Life	10000000Operations
Operating Temperature Range	-25 → +80°C
