Name: Omron E2B-S08LN04-MC-C2, Inductive Threaded Barrel Proximity Sensor, M8, 4 mm Detection, NPN NC, 12 → 24 V dc
Brand: OMRON
SKU: E2B-S08LN04-MC-C2
Availability: OutOfStock

Omron E2B-S08LN04-MC-C2, Inductive Threaded Barrel Proximity Sensor, M8, 4 mm Detection, NPN NC, 12 → 24 V dc

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron E2B-S08LN04-MC-C2, Inductive Threaded Barrel Proximity Sensor, M8, 4 mm Detection, NPN NC, 12 → 24 V dc

Part Number : E2B-S08LN04-MC-C2

Proximity sensor, inductive, stainless steel, long body, M8, unshielded, 4 mm, DC, 3-wire, NPN-NC, M8 plug-in

Availability: Sold out

Detailed Description
Specifications
Features

E2B Stainless Steel Long Body

The E2B range of stainless steel long bodied cylindrical inductive proximity sensors from Omron are designed to offer reliable performance for use with in standard industrial environments. This range of inductive sensors have an easy-to-read code. They also have a bright circular LED indicator to allow for quick visual recognition of their operating status. These two features reduce the cost and time need to for maintenance.

IP67 rated for protection in wet environments
360 ° visible LED for operation Control
Pre-wired and connector variations available
Vibration shock resistance: IEC 60947-5-2 (10 - 55 Hz)

Brand	Omron
Thread Size	M8
Sensor Technology	Inductive
Detection Range	4 mm
Body Style	Threaded Barrel
Output Function	NC
Digital Switching Output Type	NPN
Connection Type	M8
Supply Voltage	12 → 24 V dc
Length	49mm
IP Rating	IP67
Mounting Type	Non-Flush
Housing Material	Stainless Steel
Maximum DC Voltage	30V
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+70°C
Depth	6.6mm
Short Circuit Overload Protection	Yes
Reverse Polarity Protection	Yes
Switching Frequency	1 kHz

Proximity sensor, inductive, stainless steel, long body, M8, unshielded, 4 mm, DC, 3-wire, NPN-NC, M8 plug-in
