Omron E3RB-TP11 2M, Through Beam Photoelectric Sensor, Barrel Sensor, 15 m Detection Range

Name: Omron E3RB-TP11 2M, Through Beam Photoelectric Sensor, Barrel Sensor, 15 m Detection Range
Brand: OMRON
SKU: E3RB-TP11 2M
Availability: OutOfStock

Part Number : E3RB-TP11 2M

Photoelectric sensor, M18 radial, metal body, red LED, through-beam, 15m, PNP, L-ON/D-ON selectable, 2m cable

Availability: Sold out

Detailed Description
Specifications
Features

E3RB Compact Radial Photoelectric Sensors

The E3RB range of radial photoelectric sensors from Omron are simple and quick to mount and easy to set up due to the large adjuster and high power LED indicator making alignment easier. The status LED indicators of these photoelectric sensors can also be seen easily, from long distances and wide angles. The E3RB series sensors are typically installed in industrial plants such as food and beverage, textiles, food and logistics and are also designed especially for non stop detection for areas where machines never stop.

Radial type increasing the mounting flexibility
Compact design
Metal housing
Visible LED light for easy alignment
LED indication
Light-ON/Dark-ON selectable by wiring
Reversed power supply polarity protection, output short circuit protection and reversed output polarity protection

E3F2 Series Barrel

Output can be configured by wiring either ’light ON’ or ’dark ON’
Built in amplifier
Short circuit and reverse polarity protection
M18 DIN size cylindrical housing

Brand	Omron
Sensor Style	Barrel
Detection Type	Through Beam
Detection Range	15 m
Output Type	PNP
Electrical Connection	Pre-Wired Cable
Maximum DC Voltage	30V
Light Source	LED
IP Rating	IP67, IP69K
Maximum Current	40 mA
Response Time	500 μs
Minimum Operating Temperature	-25°C
Series	E3RB
Maximum Operating Temperature	+55°C
Housing Material	Nickel Plated Brass

Photoelectric sensor, M18 radial, metal body, red LED, through-beam, 15m, PNP, L-ON/D-ON selectable, 2m cable
