OMRON EE-SX675 | Through-Beam Fork Sensor | 5 mm, NPN, 4-Pin Connector
OMRON's EE-SX675 through-beam fork sensor offers a sensing distance of 5 mm and an NPN output. This model connects through a 4-pin connector, works with an infrared light source and meets IP50.
- Maximum voltage 24 V DC
- Current up to 12 mA
- 0.17 ms response time
- Works from -25 °C to +55 °C
- PBT housing
- Light-on / dark-on switching
- Detailed Description
- Specifications
- Downloads
Omron EE-SX67 Series Photoelectric Sensor, 5mm Detection Range, Infrared Light Source - EE-SX675
Features & Benefits
• Maximum detection range of 5mm improves sensing accuracy
• High-speed response time of 0.17ms ensures rapid detection
• Robust PBT housing material enhances durability in harsh conditions
Applications
• Suitable for packaging machinery requiring precise part alignment
• Can be integrated into conveyor systems for material handling
• Utilised in robotics for reliable position sensing
• Ideal for detecting objects in printing and labelling systems
What is the significance of the IP50 rating for this device?
How does the light/dark switching feature benefit installation flexibility?
What type of connection is provided with this model?
What environments are suitable for the operational temperature range of this sensor?
How does the response time of 0.17ms impact its performance?
| Brand | Omron |
| Series | EE-SX67 |
| Detection Type | Through Beam |
| Detection Range | 5 mm (0.197 in) |
| Sensor Style | Fork |
| Output Type | NPN |
| Electrical Connection | 4 Pin Connector |
| Switching Mode | Light / Dark switching |
| Light Source | Infrared |
| Response Time | 0.17 ms |
| Maximum DC Voltage | 24V |
| IP Rating | IP50 |
| Maximum Current | 12 mA |
| Minimum Operating Temperature | -25 °C (-13 °F) |
| Housing Material | PBT |
| Maximum Operating Temperature | +55 °C (131 °F) |
| Terminal Type | Connector |
| Standards Met | CE |
