OMRON G5RL-1-E-HR DC5 | G5RL Power Relay | 5 V DC Coil, SPDT, 16 A, PCB
Part Number : G5RL-1-E-HR DC5
The OMRON G5RL-1-E-HR DC5 is a PCB power relay driven by a 5 V DC coil, with an SPDT contact switching 16 A. It is rated up to 250 V AC or 24 V DC, with 100,000 electrical and 10,000,000 mechanical cycles of life.
- 5 V DC coil, 400 mW, 62.5 Ω
- SPDT, 16 A
- Up to 250 V AC / 24 V DC
- Life 100,000 electrical, 10,000,000 mechanical
- 6 kV AC coil-to-contact isolation
- 29 x 12.7 x 15.7 mm
For pricing, please contact our experts.
G5RL Series
Low noise "Silent" operation versions - almost inaudible, 44dB @ 15cm
High inrush versions - inrush peak currents up to 100A
AC versions - 24, 120 & 240Vac coils
Flux proof
8mm creepage/clearance between coil and contacts
Low profile: 15.7mm max height
High inrush versions - inrush peak currents up to 100A
AC versions - 24, 120 & 240Vac coils
Flux proof
8mm creepage/clearance between coil and contacts
Low profile: 15.7mm max height
Note
Operating temperature range -40 to 85°C (DC coil), -40 to 70°C (AC coil)
Approvals
UL, CSA, VDE
