OMRON K8AK-VW2 24VAC/DC | Voltage Monitoring Relay | 1 to 150 V AC/DC, 1 Phase, SPDT

Name: OMRON K8AK-VW2 24VAC/DC | Voltage Monitoring Relay | 1 to 150 V AC/DC, 1 Phase, SPDT
Brand: OMRON
SKU: K8AK-VW2 24VAC/DC
Availability: InStock

Part Number : K8AK-VW2 24VAC/DC

Offering voltage ranges of 1 to 10 V AC/DC, 3 to 30 V AC/DC and 15 to 150 V AC/DC, plus overvoltage and undervoltage detection, the OMRON K8AK-VW2 24VAC/DC is a single-phase voltage monitoring relay. The K8AK-VW2 24VAC/DC switches an SPDT output.

Voltage ranges: 1 to 10 V AC/DC, 3 to 30 V AC/DC, 15 to 150 V AC/DC
Detection: Overvoltage, undervoltage
Contacts: SPDT
Time delay: 0.1 to 30 s
Operating temperature: -20 to +60 °C

Availability: low stock

Detailed Description
Specifications
Downloads

Omron K8AK-VW Series Monitoring Relay, SPDT, DIN Rail Mounting - K8AK-VW2 24VAC/DC

This monitoring relay is designed for voltage oversight in industrial applications. It can detect both overvoltage and under voltage conditions, ensuring the performance and safety of essential electrical systems. Its DIN rail mounting feature enhances adaptability, making it a crucial component for professionals in automation and electrical engineering.

Features & Benefits

• Monitors overvoltages and under voltages to maintain system integrity
• Provides two programmable SPDT outputs for flexible control
• Includes manual and automatic reset options for convenience
• Equipped with LED indicators for clear status visualisation
• Offers pre-alarm monitoring to prevent serious failures
• Compatible with various input frequencies, increasing versatility

Applications

• Utilised for voltage regulation in industrial machinery
• Ideal for monitoring electrical systems in manufacturing facilities
• Applied in critical infrastructure for power management
• Used in automation control systems to protect operations
• Suitable for integration in electrical monitoring solutions across sectors

Is installation straightforward for the monitoring relay?

Yes, the relay is designed for easy DIN rail mounting, simplifying the installation process.

What type of input ranges can be monitored?

It can handle input ranges from 1V to 600V AC/DC, depending on the model.

How is the relay reset after an alarm activation?

The relay can be reset either manually or automatically, based on your configuration choice.

Can I monitor multiple operating conditions simultaneously?

Yes, it can simultaneously monitor both overvoltage and under voltage instances.

What is the operational temperature range for this device?

The relay operates effectively between -20°C and +60°C, making it suitable for various environments.

Standards

UL 60947-5-1, UL 508, IP 20

Brand	Omron
Monitoring Application	Voltage
Electrical Phase	1
Voltage Sensing Range	1 → 10 V ac/dc, 15 → 150 V ac/dc, 3 → 30V ac/dc
Contact Configuration	SPDT
Voltage Sensitivity	Overvoltage, Undervoltage
Time Delay	0.1 → 30s
Series	K8AK-VW
Height	95mm
Length	22.5mm
Minimum Operating Temperature	-20°C
Operating Temperature Range	+60°C
Minimum Voltage Sensed	1 V ac/dc, 3 V ac/dc, 15V ac/dc
Maximum Voltage Sensed	10 V ac/dc, 30 V ac/dc, 150V ac/dc
Maximum Operating Temperature	+60°C
Width	100mm
Dimensions	22.5 x 100 x 95mm
