Omron MKS2PI 48VDC, Plug In Power Relay, 48V dc Coil, 10A Switching Current, DPDT

Name: Omron MKS2PI 48VDC, Plug In Power Relay, 48V dc Coil, 10A Switching Current, DPDT
Brand: OMRON
SKU: MKS2PI 48VDC
Availability: OutOfStock

Part Number : MKS2PI 48VDC

Availability: Sold out

Detailed Description
Specifications

Omron MKS Series Power Relay, DPDT Contact Configuration, 10A Switching Current - MKS2PI DC48

This power relay delivers high performance for various applications, particularly in automation and industrial environments. It is designed to manage high switching currents, making it suitable for the reliable and efficient control of electrical devices. Its sturdy construction ensures compliance with rigorous standards, making it a preferred choice for professionals in the electronics and electrical sectors.

Features & Benefits

• DPDT configuration provides versatile control options
• Safe operation within a maximum temperature of +60°C
• Maximum switching current capacity of 10A
• Plug-in design facilitates simple installation and replacement
• Conforms to essential electrical relay specifications for consistent performance

Applications

• Utilised in automation systems for dependable device control
• Suitable for general-purpose tasks in mechanical
• Employed in electrical panel configurations to enhance efficiency
• Utilised in industrial machinery to maintain operational control

How can I ensure the relay performs optimally in my project?

It is crucial to follow the specified coil voltage and maximum switching current ratings to avoid damage.

What should I do if the relay does not switch at the expected voltage?

Check the coil resistance and confirm that all connections are secure, as poor connections can impair proper operation.

Can it be mounted in various orientations?

Yes, the plug-in design allows for flexible mounting options, suitable for different configurations.

Brand	Omron
Coil Voltage	48V dc
Contact Configuration	DPDT
Mounting Type	Plug In
Switching Current	10A
Number of Poles	2
Latching	No
Series	MKS
Terminal Type	Plug In
Maximum Switching Voltage AC	250V ac
Maximum Switching Voltage DC	250V dc
Maximum Switching Current DC	10 A
Maximum Switching Current AC	10 A
Length	34.5mm
Coil Resistance	1710Ω
Coil Power	1.4W
Maximum Operating Temperature	+60°C
Standards Met	CSA, UL
Minimum Operating Temperature	-40°C
Height	34.5mm
