Omron MY4IN-GS-R DC24, Plug In Latching Power Relay, 24V dc Coil, 6A Switching Current, 4PDT

Name: Omron MY4IN-GS-R DC24, Plug In Latching Power Relay, 24V dc Coil, 6A Switching Current, 4PDT
Brand: OMRON
SKU: MY4IN-GS-R DC24
Availability: OutOfStock

Part Number : MY4IN-GS-R DC24

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical & LED indicators, lockable push test button, 24 VDC

Availability: Sold out

Detailed Description
Specifications
Features

OMRON Power Relay, Single Coil, 2kV AC Coil-to-Contact Isolation - MY Series - MY4IN-GS-R DC24

Searching for a space-saving device that can manage multiple electrical loads at once? Reach for this miniature power relay from OMRON. It has a 4PDT configuration, so it's a practical choice when you need to control up to four individual circuits. As it's a latching relay type, this nifty piece of kit maintains its last contact position even after the input voltage has been cut. This means it needs less overall power than non-latching alternatives, helping you conserve resources.

Features & Benefits

• Compact dimensions of just 28 (H) x 21.5 (W) x 36mm (D) fit comfortably where space is limited
• Service life of 300,000 cycles, so it provides long-lasting performance
• Compatible with extreme conditions thanks to an operating temperature range of -55°C to +70°C
• Highly conductive silver contacts deliver a quality connection you can rely on

Applications

• Industrial motor control
• Commercial car washes
• HVAC systems
• Counting and sorting equipment

How do I install this relay?

For convenience, this handy device plugs quickly and easily into a compatible socket.

What are the coil and switching voltages of this component?

For maximum user safety, the low 24V DC coil voltage produces a top switching voltage of 250V AC/DC, keeping workers and equipment isolated from high-energy systems.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	24V dc
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Latching	Yes
Series	MY
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current DC	6 A
Maximum Switching Current AC	6 A
Length	28mm
Coil Resistance	662 Ω
Coil Power	900mW
Standards Met	CQC, CSA, IEC, UL
Contact Material	Silver
Isolation Coil To Contact	2kV ac
Depth	36mm

Relay, plug-in, 14-pin, 4PDT, 6 A, mechanical & LED indicators, lockable push test button, 24 VDC
