OMRON NX102-1100 | Sysmac NX1 Modular CPU | 5 MB Program, EtherCAT 4 Servo Axes

Name: OMRON NX102-1100 | Sysmac NX1 Modular CPU | 5 MB Program, EtherCAT 4 Servo Axes
Brand: OMRON
SKU: NX102-1100
Availability: InStock

Part Number : NX102-1100

The OMRON NX102-1100 is a Sysmac NX1 modular CPU with 5 MB of program and 33.5 MB of data memory. Built-in EtherCAT handles 4 servo axes and 4 PTP axes (64 EtherCAT nodes in total), and two Ethernet ports provide OPC-UA and EtherNet/IP.

EtherCAT: 4 servo axes, 4 PTP axes, 64 nodes total
Memory: 5 MB program, 33.5 MB data
2 Ethernet ports (OPC-UA, EtherNet/IP)
Supply: 24 V DC
Dimensions: 68.1 x 90 x 103 mm
0 to +55 °C

Availability: low stock

Detailed Description
Specifications
Features
Downloads

The NX1 can utilize information, take safety measures, and control quality while at the same time improving production efficiency through high-speed, high-precision control. This contributes to continuous improvement in productivity.

Fast and accurate control by synchronizing all machine devices with the PLC and Motion Engines
Three built-in industrial Ethernet ports
OPC UA server functionality
Up to 12 axes of control via EtherCAT
Up to 32 local NX I/O Units
DC power supply without battery backup
PLCopen Function Blocks for Motion Control allow users to create complex programs quickly and easily
Direct connection to a database, with no specia
unit, software, or middleware required (NX102-20)

Brand	Omron
Manufacturer Series	NX102
For Use With	Machine Automation Controller NX1
Voltage Category	24 V dc
Network Type	EtherCAT, EtherNet/IP
Width	90mm
Minimum Operating Temperature	0°C
Maximum Operating Temperature	+55°C
Dimensions	68.1 x 90 x 103 mm
Number of Communication Ports	3
Battery Backup	Yes
Programming Language Used	Ladder Diagram
Mounting Type	Panel Mount
Length	68.1mm
Depth	103mm
Program Capacity	5 MB
Programming Interface	Ethernet
Communication Port Type	RJ45

Sysmac NX1 Modular CPU, 5MB program and 33.5MB data memory , built-in EtherCAT (4 servo axes, 4 PTP axes, total 64 EtherCAT nodes), 2 Ethernet ports (OPC-UA and EtherNet/IP)
