ifm PN3006 | Pressure Sensor | 18-36 DC V
The ifm PN3006 is a pressure sensor with output function normally open / closed; (configurable), electrical design PNP and operating voltage 18-36 DC V. ifm lists with programmable switching output and analog output, clearly visible 4-digit LED display and country-specific pressure units selectable among its features.
- Ambient temperature: 20 °C to 80 °C
- Current consumption: <50
- Electrical design: PNP
- Operating voltage: 18-36 DC V
- Output function: normally open / closed; (configurable)
- Protection class: III
- Reverse polarity protection: yes
- Short-circuit protection: yes
- Specifications
- Features
- Downloads
| Ambient Temperature | -20 °C to 80 °C (-4 to 176 °F) |
| Current Consumption [mA] | <50 |
| Electrical Design | PNP |
| Operating Voltage [V] | 18-36 DC V |
| Output Function | normally open / closed; (configurable) |
| Protection Class | III |
| Reverse Polarity Protection | yes |
| Short-circuit Protection | yes |
| Switching Frequency DC [Hz] | <170 Hz |
| System | gold-plated contacts |
- With programmable switching output and analog output
- Clearly visible 4-digit LED display
- Country-specific pressure units selectable
- With long-term stability thanks to high overload protection
- High shock and vibration resistance
