REED R8070SD Data Logging Sound Level Meter
This noise dosimeter can record sound levels (dB) and sound exposure (dose percent) over an 8-hour period in order to calculate an individual's sound exposure. The R8085 is a small and lightweight dosimeter that meets OSHA and CCOHS noise survey criteria (Canadian Centre for Occupational Health and Safety).

Free UAE shipping available
- Specifications
- Features
- Downloads
Dimensions | 9.7 x 2.7 x 1.8" (245 x 68 x 45mm) |
Display | 4-digit LCD |
Operating Humidity Range | Less than 85% RH |
Operating Temperature | 32 to 122°F (0 to 50°C) |
Power Supply | 6 x AA Batteries or AC Adapter (optional) |
Resolution | 0.1dB |
Response Time | 500ms |
Storage Temperature | 14 to 140°F (-10 to 60°C) |
Weight | 0.7lbs (320g) |
High accuracy of ±1.0dB to 1kHz meets Type 2 standards
Triple range measurement (50dB dynamic range)
A & C frequency weighting
Fast & Slow time weighting
Real-time data logger with integrated SD memory card
User selectable sampling rate from 1 to 3600 seconds
Peak hold, Data hold and Min/Max hold
Easy-to-read backlit LCD display
Tripod mount for long-term monitoring
Low battery indicator and auto shut off
The single AC output jack (3.5mm stereo mini-plug) provides analog signals to frequency analysers, level recorders, FFT analysers, graphic recorders, etc.
