SMC KQ2L06-00A | Union Elbow Fitting | Tube-to Tube Adaptor | Series KQ2 | Tube Size 6mm
There are numerous sizes, body shapes, and thread types available for KQ2 one-touch, metric, and inch size fittings. Positive sealing under pressure is achieved by the specifically made packing without the decreased flow that is typical of compression fittings. The chuck and collet are both released by the KQ2 release collar, which also offers a low disconnection force for simple tubing removal.
- Specifications
- Features
- Downloads
| Body Material | PBT |
| Connection Size | A: Push In 6 mm |
| Connection Size | B: Push In 6 mm |
| Connection | A: Tube-to-Tube |
| Connection | B: Push In |
| Fluid | Water / Air |
| Maximum operating temperature | +60°C |
| Minimum Operating Temperature | -5°C |
| Series | KQ2 |
| Type | Union Elbow Fitting |
| Weight | 6.92 G |
- Takes urethane and nylon tubes
- Suitable for situations involving both positive pressure and vacuum
- Tubing may be easily removed without causing damage thanks to the release collar.
- 1.0 MPa is the maximum vacuum pressure.
