Sauermann CP 212 | Pressure Transmitter | -1000 to +1000 Pa
The Sauermann CP 212 is a pressure transmitter with range -1000 to +1000 Pa, accuracy +/-0.5% of reading +/-2 Pa and IP65 protection.
- Accuracy: +/-0.5% of reading +/-2 Pa
- IP PROTECTION RATING: IP65
- Operating Temperature: 10 to +50°C
- Power Supply: 24 Vac / Vdc +/-10% 100-240 Vac, 50-60 Hz
- Range: -1000 to +1000 Pa
- Storage Temperature: 10 to +70°C
- Specifications
- Features
- Downloads
| Accuracy | +/-0.5% of reading +/-2 Pa |
| Brand | Sauermann |
| IP PROTECTION RATING | IP65 |
| Operating Temperature | -10 to +50°C |
| Part number | CP 212 |
| Power Supply | 24 Vac / Vdc +/-10% 100-240 Vac, 50-60 Hz |
| Range | -1000 to +1000 Pa |
| Storage Temperature | -10 to +70°C |
Input Pt100 on terminal block for temperature measurement, range from -100 to +400°C (probes as option)
• Configurable intermediate ranges
• Power supply 24 Vdc/Vac or 100-240 Vac
• Trend indicator
• “¼ turn” system mounting with wall-mount plate
