      Winters PFP1095ZRR1R11 | Premium Stainless Steel StabiliZR Gauge | 0-160 psi / 0-11 bar | 4” (100mm) Dial Display | ±1% Accuracy | 1/4" Back
StabiliZRTM gauges are dry gauges with a StabiliZRTM dampened movement that minimizes vibration and pulsation-induced pointer flutter. It's a lot easier to read pressure now.There's no need to be concerned about fill fluid spilling or process media compatibility. Without the trouble of draining and refilling the case with fill fluid, gauges can be serviced quickly. Ideally suited for process, chemical and petroleum industry. Where chemical compatibility and contamination is a concern
- Specifications
 - Features
 - Downloads

| Accuracy | +/-1% |
| Connection | 1/4� Back |
| Dial Size | 4� (100mm) |
| Material | SS/SS |
| Range | 0-160 psi / 0-11 bar |
| Type | Stabilizr Gauges |
StabiliZRTM dampened movement minimizes effects of pulsation and vibration without liquid filling
• Restrictor screw
• Stainless steel case
• Under and overload stops (4” and 6”)
• Back, bottom or panel mounted
• 316L SS wetted parts
• ASME B40.100 compliant (EN837-1 available)
• CRN registered
• 5 year warranty
