Aim-TTi PSA1303USC Handheld Spectrum Analyser, 1.3GHz

Name: Aim-TTi PSA1303USC Handheld Spectrum Analyser, 1.3GHz
Brand: Aim Tti
SKU: PSA1303USC
Availability: InStock

Part Number : PSA1303USC

Availability: low stock

Detailed Description
Specifications
Downloads

Aim-TTi PSA Series 3 Series Spectrum Analyser, 1.3 GHz Bandwidth, 3 h Battery Life - PSA1303USC

This handheld spectrum analyser by Aim-TTi, the PSA Series 3 - USC, with 1.3 GHz bandwidth, is designed to offer exceptional performance in a compact size. It features a TFT display, RF input via N Connector, and USB interface for connectivity. With a focus on portability and functionality, this spectrum analyser is ideal for various applications in the electronics and automation industries.

Features & Benefits

• Handheld spectrum analyser with 1.3 GHz bandwidth
• Compact design with a 4.3-inch TFT display for easy operation
• RF Input via N Connector for accurate measurements
• USB Interface for data transfer and connectivity
• Lightweight and portable, weighing only 580g
• Battery operation of more than 3 hours for on-the-go use
• Zero Span mode with AM and FM audio demodulation
• Live, view, and reference traces for comprehensive analysis
• Dual markers with smart movement for precise measurements
• Frequency counter with 10Hz resolution for accuracy

Applications

• Interference analysis in radio communication field environments
• Antenna alignment and signal strength mapping
• Covert transmitter detection and spurious emissions evaluation
• EMC frequency evaluations and detection of abnormal frequencies

Can it operate for more than 3 hours on battery?

Yes, it offers a battery life of more than 3 hours for continuous operation.

Will it provide detailed trace and analysis features?

Yes, it includes live, view, and reference traces with smart marker movement for precise measurements.

Is it suitable for interference analysis in radio communication fields?

Yes, it is designed for applications like antenna alignment, signal strength mapping, and spurious emissions detection.

Brand	Aim-TTi
Bandwidth	1.3GHz
Number of Channels	1
Wave Traces	Live, Reference
Sweep Modes	Continuous, Single
Setting Modes	Zero Span
Series	PSA Series 3
Maximum Frequency	1.3GHz
Minimum Frequency	1 MHz
Frequency Stability	1PPM
Display Type	TFT
Screen Size	4.3 in
Markers	Dual
RF Input	N Connector
Interface Type	USB
Desktop/Handheld	Handheld
Width	49mm
Maximum Operating Temperature	+40°C
Battery Type	Li-ion
Plug Type	Universal
