ASCO 52100005, 5/2 Pneumatic Solenoid Valve - Solenoid/Pilot G 1/4 521 Series 24V dc
Part No. 52100005
The ASCO 52100005 is a Series 521 5/2 solenoid valve with G 1/4 ports and a 24 V DC coil. It switches compressed air to drive cylinders and actuators from your control system. Genuine stock at General Tech Services LLC, UAE, with free UAE-wide shipping. Request a quote in under a minute - call +971 6 543 6933.
Every automated cylinder needs a reliable valve between the control system and the air supply. The ASCO 52100005 is a 5/2 valve with supply, two outlets and two exhausts, making it suitable for driving a double-acting cylinder in both directions, with G 1/4 ports.
Actuation is listed as solenoid / pilot, and the 24 V DC coil connects directly to compatible control voltages for repeatable switching during machine operation. It is supplied as genuine ASCO stock.
Typical uses include double-acting cylinders on automated machines, control panels running 24 V DC coils, and maintenance teams replacing a like-for-like ASCO Series 521 valve. When selecting a replacement, confirm the valve function, actuation and return type, port size and coil voltage.
Ready to order the ASCO 52100005? Speak to our team. Call +971 6 543 6933
Key Benefits
-
5/2 function
-
G 1/4 ports
-
24 V DC operation
-
Solenoid / pilot actuation
-
Genuine ASCO (Emerson) product and specification
-
Free UAE-wide shipping on genuine ASCO stock
Who This Product Is Best For
-
Double-acting cylinders on automated machines
-
Control panels running 24 V DC coils
-
Maintenance teams replacing a like-for-like ASCO Series 521 valve
How to Install & Use It
-
Confirm the function, actuation, port size and voltage match your circuit.
-
Mount the valve and connect the supply, outlet and exhaust ports as marked.
-
Wire the coil to your control output at the correct voltage.
-
Test switching with the actuator unloaded, then under working pressure.
Frequently Asked Questions
What does the ASCO 52100005 do?
It is a 5/2 valve used to switch compressed air for controlling pneumatic actuators such as double-acting cylinders in both directions.
What does 5/2 mean?
5/2 means 5 ports and 2 positions: a supply port, two outlet ports and two exhaust ports.
What voltage and port size does it use?
It uses a 24 V DC coil and has G 1/4 ports.
What type of actuation does it use?
The ASCO 52100005 uses solenoid / pilot actuation.
What air quality does it need?
Use clean, dry, filtered compressed air. Good air preparation with a filter and regulator helps protect pneumatic components and maintain consistent switching.
Can you supply matching ASCO parts in the same order?
Yes. General Tech Services LLC can supply ASCO solenoid and spool valves, shut-off valves, silencers, filters, regulators, cylinders and position detectors. Contact our team with your application requirements for compatible parts.
Should I choose this model or the ASCO 52100008?
Choose the valve based on the required function, actuation, port size, coil voltage and application requirements. The ASCO 52100005 has a 5/2 function and 24 V DC coil, while the 52100008 has a 5/2 function and 230 V AC coil. Send your application details or existing part number to General Tech Services LLC for compatibility confirmation.
What details should I send with a quote request?
Share the part or model number, quantity and application details such as size, pressure, flow and operating environment. This helps confirm the exact ASCO variant and provide accurate pricing and lead-time information.
Is genuine ASCO stock available in the UAE?
General Tech Services supplies original ASCO valves in the UAE with technical support and free UAE-wide shipping.
What is the price of the ASCO 52100005?
Pricing is quote-based. Call General Tech Services LLC on +971 6 543 6933 or submit the Request a Quote form.
For pricing or to place an order, contact General Tech Services LLC. Call +971 6 543 6933.
