ASCO 52100078 | 5/2 Pneumatic Solenoid Valve | Pilot/Pilot G 1/4 521 Series
Pneumatic cylinder piloting is best suited for the solenoid air-operated, mini-spool AVENTICS Series 521 valves. The valves have premium coils that are resistant to heat and moisture, making them appropriate for hard settings and high ambient temperatures. They can be installed for a variety of uses on joinable subbases. Applications for the AVENTICS Series 521 valves include tire production, automotive, case packing, and packaging.

Free UAE shipping available
- Specifications
- Features
- Downloads
Activation | Pneumatically |
Actuating control | Double Air Pilot |
Control pressure max. | 8 bar |
Control pressure min. | 1.5 bar |
Nominal flow Qn | 1050 l/min |
Oil content of compressed air max. | 5 mg/m3 |
Oil content of compressed air min. | 0 mg/m3 |
Output | Compressed air connection output : G 1/4 |
Size | Max. particle size5 µm |
Switching principle | 5/2 |
Type | Connection type : Pipe connection |
Valves | Spool valve |
Weight | 0.11 kg |
Working pressure max | 8 bar |
Working pressure min. | 0 bar |
- G1/4-tapped, anodized aluminum body with NBR seals for longer service life.
- non-breathing design in which the solenoid valve exhaust is collected with the spring return chambers of the single- or double-acting actuator.
- manages neutral gas or lubricated or unslubricated air.
- 5°C to 50°C is the ambient temperature range.
- with all applicable EU directives.
