AVENTICS 1323202000 | ICM Double-Acting Roundline Cylinder | 32 mm Bore, 25 mm Stroke
Part Number : 1323202000
Stroke length on the AVENTICS 1323202000 is 25 mm and the bore measures 32 mm, in a double-acting ICM roundline cylinder. This 32 x 25 mm version connects via G 1/8 ports, carries a male-threaded piston rod and is rated to 10 bar between -20 °C and +70 °C.
- 32 mm bore / 25 mm stroke
- Double-Acting operation
- Port size G 1/8
- Male piston rod thread
- Elastic end cushioning
- 10 bar max pressure, temperature -20 °C to +70 °C
For pricing, please contact our experts.
