Chicago Pneumatic CP3019-20ES | Angle Die Grinder | 1/4 in collet, 20,000 rpm, 375 W
With 20,000 rpm free speed, a 375 W motor and a 1/4 in (6.35 mm) collet, the Chicago Pneumatic CP3019-20ES is an angle die grinder. The CP3019-20ES measures 249 mm overall and weighs 0.57 kg.
- Compact industrial angle die grinder; 20,000 rpm free speed
- Up to 2,000 hours between maintenance intervals in demanding applications; 375 W motor
- Ergonomic design aimed at productive work; 249 mm overall length
- 1/4 in air inlet, minimum hose size 8 mm and 8.5 l/s air consumption under load
- Declared vibration 3.7 m/s², sound pressure 73.8 dB(A) and sound power 84.8 dB(A)
- Specifications
- Features
| Part Number | CP3019-20ES |
| Brand | Chicago Pneumatic |
| Product Number | 6151602170 |
| Free speed | 20,000 rpm |
| Power | 375 W |
| Collet size | 1/4 in (6.35 mm) |
| Air inlet thread | 1/4 in |
| Air consumption (under load) | 8.5 l/s |
| Min. hose size | 8 mm |
| Length | 249 mm |
| Net weight | 0.57 kg |
| Vibration | 3.7 m/s² |
| Sound pressure | 73.8 dB(A) |
| Sound power | 84.8 dB(A) |
- Compact body
- Insulating composite over-housing
- Streamlined safety lever
- Rear exhaust
- 1/4" (6.35 mm) collet holder
- Extended body
- 0.5 hp (375 W) governed motor
- 20,000 rpm free speed
