CONCOA 8066740-01-1 | 6700 Series Manifold Regulator | Fuel Gas, 40 PSIG Delivery, RH Inlet
Part Number : 8066740-01-1
The CONCOA 8066740-01-1 serves fuel gas manifolds, with the inlet positioned RH. A chloroprene seat controls delivery pressure up to 40 PSIG (3 BAR), shown on 0-60 PSIG/0-400 kPa and 0-400 PSIG/0-2800 kPa gauges.
Key features
- 1/2 in FNPT inlet and outlet ports, plus a brass barstock body
- 1/4 in FNPT gauge and relief ports, plus a balanced stem seat that steadies output as inlet pressure decays
- A 3000 PSIG (210 BAR) maximum inlet rating without peripherals, plus a rugged forged brass bonnet
- A 40-micron 316L stainless steel filter and a diaphragm of chloroprene
For pricing, please contact our experts.
