Dwyer Instruments 215 | Solid plastic stationary gage | Range .05-0-.25" w.c. | .005 minor div. | 6" scale | 2 lb 14 oz

Client Protection

Dedicated Support

Genuine Products

Client Protection

Dedicated Support

Genuine Products

Part Number : 215

For very precise laboratory or general industrial operation, Dwyer® Series 200 Durablock® Solid Plastic Stationary Gages, also known as draft gages, are available in inclined and vertical (well-type) forms for the measurement of low range gas and air pressures, positive, negative, or differential. Because Dwyer has fabricated acrylic instruments for many years, all bore and well machining is done to the highest standards of precision to ensure the accuracy needed in instruments of this kind.

Availability: Sold out

Free UAE shipping available

Specifications
Features
Downloads

Accuracy	+/-1%
Maximum Operating Pressure	0.25Inch-H2O
Maximum operating temperature	150°F
Minor Division	0.005
Range	.05-0-.25" w.c.
Scale	6"
Type	Inclined Tube Manometer
Weight	2 lb 14 oz

Sensitivity range:.05-0-.25" w.c.,.005 minor division, 6" scale, weight: 2 lbs., 14 oz.
1" Thick Acrylic Plastic The body is a single, nearly indestructible block that is stable and free from distortion risk.
Without any kinks or dents, the drilled bore is accurate to ±.0002" and won't need to be recalibrated due to distortion.
Particular Gauge For the most precise readability, a fluid with good wetability properties generates a consistent, well-shaped meniscus.
Easily zero in with these polished aluminum adjustable reflective scales that lock with a thumbscrew.
To get optimal precision and consistency in parallax-free reading, just align the meniscus with the picture reflected in the scale.
Over-Pressure Protection Traps stop fluid loss brought on by pressure surges or over range pressures.
For inclined style gauges, leveling adjustment is as easy as removing a locking thumb screw located on the gage's side or bottom and adjusting in relation to the integral.

DOWNLOAD CATALOG
