Dwyer Instruments 3HBAV0612 | Three-Way detachable electric ball valve | Cv value 27.9 | 1-1/2" NPT | 120 VAC | floating
A three-way detachable electric ball valve in 1-1/2" NPT with a Cv of 27.9, floating control and a 120 VAC actuator, built for mixing and diverting duty in hot- and chilled-water HVAC loops. Free UAE shipping.
Request a quote in under a minute - call +971 6 5436933.
Part No. 3HBAV0612
The Dwyer 3HBAV0612 combines a 3-way ball valve body in 1-1/2" NPT with a detachable electric actuator, providing automated mixing or diverting control for hot- and chilled-water circuits in HVAC, heating and industrial water systems.
The actuator includes position switches and a local position indicator and can be detached from the valve body for servicing without breaking the pipe connection. The valve accepts a floating three-point control signal, allowing the actuator to open, close or stop in response to commands from a BMS or local controller.
With a rated flow coefficient of Cv 27.9, the 3HBAV0612 is suited to 1-1/2" NPT branch and mixing circuits where one valve is required to blend or route flow between ports rather than simply shut off a single line.
The 3HBAV0612 is part of Dwyer Instruments' dedicated product line-up carried by GeneralTech Shop. Contact our team if you need assistance confirming the correct variant for your application.
Ready to order the 3HBAV0612?
Speak to our team for pricing, availability and application assistance. Call +971 6 5436933.
Key Benefits
- 3-way valve body for mixing or diverting applications
- Detachable electric actuator for easier servicing
- Position switches and local position indication
- Manual override for local operation
- Floating three-point control for automated open/close/stop sequencing
- 120 VAC actuator supply for compatible control systems
- Cv 27.9 flow coefficient for 1-1/2" NPT branch and mixing applications
Who This Product Is Best For
- HVAC contractors requiring automated 3-way mixing or diverting control
- Building automation integrators using floating three-point BMS control
- Heating and chilled-water systems requiring automated flow routing or blending
- Industrial water applications using 1-1/2" NPT piping and electric actuation
How to Use
- Install the 3HBAV0612 at the required 3-way mixing or diverting point using the 1-1/2" NPT connections.
- Connect the 120 VAC actuator supply according to the installation requirements.
- Wire the floating three-point control inputs to the BMS or local controller.
- Configure the controller for the required open, close and stop operation.
- Test the valve through its operating range and verify that flow is correctly mixed or diverted between the required ports.
Frequently Asked Questions
What does a 3-way valve like the 3HBAV0612 do?
A 3-way valve can mix or divert flow between ports from a single valve body. This makes it suitable for applications such as blending hot and chilled water or routing flow through a bypass.
What control signal does the 3HBAV0612 use?
The 3HBAV0612 uses floating three-point control, providing open, close and stop commands.
What supply voltage does the 3HBAV0612 require?
The actuator requires a 120 VAC supply.
What is the Cv of the 3HBAV0612?
The rated flow coefficient is Cv 27.9.
What NPT size is the 3HBAV0612?
The valve has 1-1/2" NPT connections.
Can the actuator be removed for servicing?
Yes. The 3HBAV0612 features a detachable actuator that can be removed from the valve body without breaking the pipe connection. It also includes a manual override.
Is the 3HBAV0612 suitable for BMS applications?
Yes. Its floating three-point control can be connected to a BMS or local controller for automated valve positioning.
Does GeneralTech Shop deliver the 3HBAV0612 across the UAE?
Yes. For availability and delivery information, call +971 6 5436933 and our team will confirm the details for your location.
Is a calibration certificate available for the 3HBAV0612?
Certification and calibration details are not specified in the supplied product information. Call +971 6 5436933 and our team can confirm what documentation is available for your order.
