Dwyer Instruments TUF-1000-BN | Tenant ultrasonic BTU flowmeter | DN100 pipe size and 60 m3/h permanent flow rate with BACnet® communication
The Dwyer TUF-1000-BN is a tenant ultrasonic BTU flowmeter designed for DN100 piping and a 60 m³/h permanent rated flow. It combines ultrasonic flow measurement, temperature sensing and energy calculation in one compact unit, with BACnet® MSTP communication for integration with building management and utility billing systems.
Part Number: TUF-1000-BN
Genuine Control Techniques stock at General Tech Services LLC, UAE, with free UAE-wide shipping. Request a quote in under a minute — call +971 6 5436933.
Product Overview
The Dwyer Series TUF Ultrasonic Energy Meter provides accurate and stable measurement of heating and cooling energy consumption in clean, compatible liquids. The TUF-1000-BN is the DN100 version, rated for a 60 m³/h permanent flow rate, making it suitable for larger HVAC systems, building energy monitoring and utility sub-metering applications.
The unit combines a flowmeter, temperature sensors and an energy calculator into one compact device, reducing the need for multiple measurement instruments. It is suitable for applications involving chillers, boilers, radiators, fan coil units and individual tenant or apartment piping where heating and cooling energy consumption needs to be monitored.
The ultrasonic measurement principle uses no moving parts, helping reduce mechanical wear and maintenance requirements compared with mechanical BTU meters. An integrated 8-digit LCD provides local readings of temperature, flow rate and energy consumption directly at the meter.
For building automation and utility management, the TUF-1000-BN provides BACnet® MSTP communication, allowing measured data to be transferred to compatible BMS and billing systems.
The meter features a plastic housing with brass and 316L stainless steel wetted parts and an IP65 enclosure rating. It supports horizontal or vertical installation, with horizontal pipe runs requiring installation at least 45° from horizontal to help prevent debris accumulation.
The DN100 model uses a GB9119 flange, DN100 PN16 connection. It operates from a 24 Vac/Vdc supply and can use a user-supplied 3.6V ER26500 lithium battery for backup.
For installations requiring Modbus communication instead of BACnet, the TUF-1000-MD uses the same DN100 flowmeter body and specifications with Modbus RTU communication.
Key Benefits
- Combines ultrasonic flow measurement, temperature sensing and energy calculation in one compact unit
- DN100 configuration with a 60 m³/h permanent rated flow
- No moving parts, helping reduce maintenance requirements
- 8-digit LCD for local temperature, flow and energy readings
- BACnet® MSTP communication for BMS and utility billing integration
- IP65-rated plastic housing with brass and 316L stainless steel wetted parts
- GB9119 flange, DN100 PN16 connection
- 24 Vac/Vdc power supply with optional lithium battery backup
- Suitable for tenant-level and building-level heating and cooling energy metering
- Free UAE-wide shipping on genuine Dwyer stock
- Call +971 6 5436933 for pricing and availability
Who This Product Is Best For
- Landlords and property managers requiring tenant-level heating or cooling BTU billing
- Building owners monitoring chillers, boilers, radiators or fan coil units
- BMS integrators using BACnet® MSTP for utility sub-metering
- HVAC and building-services professionals requiring ultrasonic energy measurement for larger pipe systems
- Facilities teams monitoring heating and cooling energy consumption
How to Specify & Commission It
- Confirm that the DN100 pipe size and 60 m³/h permanent rated flow are suitable for the installation and expected load.
- Install the meter using the GB9119 flange, DN100 PN16 connection, following the specified mounting orientation. On horizontal pipe runs, install at least 45° from horizontal.
- Connect the 24 Vac/Vdc power supply and install the optional 3.6V ER26500 lithium battery if power-loss backup is required.
- Connect the BACnet® MSTP communication output to the compatible BMS or billing system and configure the required communication parameters.
- Verify the flow, temperature and energy readings on the local 8-digit LCD before commissioning and handover.
Frequently Asked Questions
What pipe size and flow rate is the Dwyer TUF-1000-BN designed for?
The TUF-1000-BN is designed for DN100 piping with a 60 m³/h permanent rated flow.
What communication protocol does the TUF-1000-BN use?
This variant uses BACnet® MSTP communication for integration with compatible building management and utility billing systems.
What is the BTU accuracy of the TUF-1000-BN?
The meter provides BTU accuracy Class 2 according to EN1434/CJ128, with flow accuracy of ±(2+(0.02 Qp/Q))% and temperature accuracy of ±0.1°C (±0.18°F).
What is the maximum operating pressure?
The maximum operating pressure is 362 psi (25 bar).
What connection does the DN100 model use?
The TUF-1000-BN uses a GB9119 flange, DN100 PN16 connection.
What power supply does the TUF-1000-BN require?
The meter operates on 24 Vac/Vdc. A user-supplied 3.6V ER26500 lithium battery can be used for backup.
What is the difference between the TUF-1000-BN and TUF-1000-MD?
Both models use the same DN100 flowmeter body and specifications. The communication protocol differs: the TUF-1000-BN uses BACnet® MSTP, while the TUF-1000-MD uses Modbus RTU.
Is the TUF-1000-BN suitable for tenant energy billing?
Yes. Its integrated flow measurement, temperature sensing and energy calculation make it suitable for tenant-level heating and cooling energy monitoring and utility billing applications.
Is genuine stock available with UAE shipping?
Yes. Genuine Dwyer stock with free UAE-wide shipping is available. Call +971 6 5436933 for current pricing and availability.
