Flexbar 16346 | Chamfer Gauge | 0-90°, 25-50 mm
Part Number : 16346
Flexbar 16346 is a dial chamfer gauge covering a 25-50 mm diameter capacity with a 0-90° angle range. It reads the diameter of chamfers and tapered holes directly from the dial, in metric units to 0.01 mm. Typical jobs include in-process and final inspection of countersinks and chamfered bores.
Key features
- Capacity 25-50 mm, angle range 0-90°
- Direct diameter reading to 0.01 mm
- Zeroed on a surface plate; no setting masters needed
- Hardened, precision-ground three-blade steel plunger for repeatable readings
- For tapered holes whose included angle is less than the angle printed on the dial
To measure, hold the gauge just above the large body diameter, insert the plunger into the hole, press firmly against the part and twist slightly to centre it.
For pricing, please contact our experts.
