HIOKI DT4256 | DIGITAL MULTIMETER

Name: HIOKI DT4256 | DIGITAL MULTIMETER
Brand: Hioki
SKU: DT4256
Availability: InStock

Part Number : DT4256

The Hioki DT4200 Digital Multimeter Series consist of a complete lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super fast response rate and safety features that take electrical testing to a higher level. The DT4256 is a digital multimeter designed to deliver maximum functionality for use in a wide range of settings.

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Current range	AC- 600.0 mA to 10.00 A, 3 ranges, Basic accuracy 40 - 500 Hz : +/-1.4 % rdg. +/-3 dgt. (True RMS, crest factor 3, 40 Hz to 1 kHz)
Current range	DC - 60.00 mA to 10.00 A, 4 ranges, Basic accuracy: +/-0.9 % rdg. +/-3 dgt.
Dimensions (mm)	84 mm (3.31 in)W ƒ- 174 mm (6.85 in)Hƒ- 52 mm (2.05 in)D, 390 g (13.8 oz) (including batteries and holster)
Frequency (Hz)	99.99 Hz (5 Hz or more) to 99.99 kHz, 4 ranges (limited by the minimum detectable voltage and current), Basic accuracy: +/-0.1 % rdg. +/-1 dgt.
Power Supply	LR03 alkaline batteries ƒ-4, Continuous use: 130 hours (backlight OFF)
Voltage	AC- 6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz to 1 kHz Basic accuracy 40 - 500 Hz : +/-0.9 % rdg. +/-3 dgt. (True RMS, crest factor 3)
Voltage	DC- 600.0 mV to 1000 V, 5 ranges Basic accuracy: +/-0.3 % rdg. +/-3 dgt.

• ±0.3% DC V basic accuracy, wide 40 Hz to 1 kHz AC V frequency characteristics

• Measure up to 10A with direct input

• Dual display lets you check voltage and frequency simultaneously

• Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)

• USB communications function supports PC measurements (optional)

• Broad -25 (-13°F) to 65°C (149°F) operating temperature range (DT4256)
