Name: ifm I12001, Inductive Smooth Barrel Proximity Sensor, 70 mm Detection NO, 90 → 250 V ac
Brand: ifm
SKU: I12001
Availability: OutOfStock

ifm I12001, Inductive Smooth Barrel Proximity Sensor, 70 mm Detection NO, 90 → 250 V ac

Client Protection

Dedicated Support

Client Protection

Dedicated Support

ifm I12001, Inductive Smooth Barrel Proximity Sensor, 70 mm Detection NO, 90 → 250 V ac

Part Number : I12001

Availability: Sold out

Detailed Description
Specifications

The ifm electronic inductive area sensor is meticulously designed to deliver reliable and precise sensing capabilities across a variety of applications. Engineered with a cylindrical housing, this sensor boasts a sleek yet robust profile that is capable of withstanding challenging environmental conditions, thanks to its IP65 protection rating. The device operates efficiently within a wide voltage range, thereby enhancing its versatility in different setups. With a generous sensing range adjustable from 20 to 70 mm, it delivers outstanding performance in detecting metallic objects with a high degree of accuracy.

Long sensing range of 70 mm
Active base with 100 mm diameter
For applications in the steel and metal industries
Easy setting of the sensing range via potentiometer
With AC output for use in AC power mains

Brand	ifm
Sensor Technology	Inductive
Body Style	Smooth Barrel
Detection Range	70 mm
Output Function	NO
Connection Type	Pre-Cabled
Cable Length	2m
Supply Voltage	90 → 250 V ac
Length	40mm
IP Rating	IP65
Mounting Type	Non-Flush
Diameter	100 mm
Series	I12
Switching Frequency	5 Hz
Shielding	Unshielded
Switching Current	200 mA
