ifm I15005, Inductive Smooth Barrel Proximity Sensor, 70 mm Detection, PNP NO+NC, 10 → 36 V dc

Name: ifm I15005, Inductive Smooth Barrel Proximity Sensor, 70 mm Detection, PNP NO+NC, 10 → 36 V dc
Brand: ifm
SKU: I15005
Availability: OutOfStock

Part Number : I15005

Availability: Sold out

Detailed Description
Specifications
Downloads

The ifm electronic inductive area sensor is engineered to enhance precision in industrial applications. Designed with a robust cylindrical housing and a notable sensing range of 20 to 70 mm, it offers reliability and accuracy in various operational environments. The device features a permanent current rating of 250 mA along with integrated short-circuit and overload protection to ensure ongoing performance under demanding conditions.

Long sensing range of 70 mm
Active base with 100 mm diameter
For applications in the steel and metal industries
Easy setting of the sensing range via potentiometer
DC version

Brand	ifm
Sensor Technology	Inductive
Body Style	Smooth Barrel
Detection Range	70 mm
Output Function	NO+NC
Digital Switching Output Type	PNP
Connection Type	Pre-Cabled
Cable Length	2m
Supply Voltage	10 → 36 V dc
Length	40mm
IP Rating	IP65
Mounting Type	Non-Flush
Diameter	100 mm
Series	I15
Shielding	Unshielded
Switching Current	250 mA
Switching Frequency	5 Hz
