ifm IC5005, Inductive Block Proximity Sensor, 40 mm Detection, PNP NO/NC, 10 → 36 V dc

Name: ifm IC5005, Inductive Block Proximity Sensor, 40 mm Detection, PNP NO/NC, 10 → 36 V dc
Brand: ifm
SKU: IC5005
Availability: OutOfStock

Part Number : IC5005

Availability: Sold out

Detailed Description
Specifications

Rectangular Inductive Proximity Sensor

Features and benefits

Very long sensing range

Easy setting of the sensing range via potentiometer

Large active sensor face

Output function normally open / normally closed programmable

Robust housing for use in harsh industrial environments

Brand	ifm
Sensor Technology	Inductive
Detection Range	40 mm
Body Style	Block
Output Function	NO/NC
Digital Switching Output Type	PNP
Connection Type	Screw Terminal
Supply Voltage	10 → 36 V dc
IP Rating	IP65
Length	90mm
Mounting Type	Non-Flush
Housing Material	PPE
Width	60mm
Maximum DC Voltage	36V
Minimum Operating Temperature	-25°C
Reverse Polarity Protection	Yes
Switching Current	250 mA
Maximum Switching Frequency	15Hz
Shielding	Unshielded
Depth	40mm
Short Circuit Overload Protection	Yes
