ifm IF5766, Inductive Threaded Barrel Proximity Sensor, M12, 2 mm Detection, 2-Wire NO/NC, 10 → 36 V dc

Name: ifm IF5766, Inductive Threaded Barrel Proximity Sensor, M12, 2 mm Detection, 2-Wire NO/NC, 10 → 36 V dc
Brand: ifm
SKU: IF5766
Availability: OutOfStock

Part Number : IF5766

Availability: Sold out

Detailed Description
Specifications
Downloads

The ifm electronic inductive sensor is a cutting-edge solution designed for precise detection in various industrial applications. Engineered with versatility, this sensor features selectable output functions, allowing it to operate as normally open or normally closed. With a robust design and compact dimensions, it seamlessly integrates into tight spaces, making it an excellent choice for both new installations and retrofitting existing systems. The sensor boasts an impressive sensing range of 2mm, and is built to withstand challenging environments, ensuring reliable performance in temperatures ranging from -25 to 80 degrees Celsius. Additionally, the unit incorporates advanced protection features, including short-circuit and overload protection, enhancing its durability and longevity. Suitable for a variety of materials, the sensor is an indispensable tool for optimising automation processes and ensuring operational efficiency.

Output function normally open or normally closed programmable
Two-wire technology
Wide operating temperature range
Robust metal housing for use in harsh industrial environments
Very high switching frequency

Brand	ifm
Thread Size	M12
Sensor Technology	Inductive
Detection Range	2 mm
Body Style	Threaded Barrel
Output Function	NO/NC
Digital Switching Output Type	2-Wire
Cable Length	2m
Connection Type	Pre-Cabled
Supply Voltage	10 → 36 V dc
Length	71mm
IP Rating	IP67
Mounting Type	Flush
Switching Frequency	1.1 kHz
Series	IF5
Switching Current	400 mA
Shielding	Shielded
