ifm IIS700, Inductive Threaded Barrel Proximity Sensor, M30, 15 mm Detection, NPN NO, 10 → 30 V dc

Name: ifm IIS700, Inductive Threaded Barrel Proximity Sensor, M30, 15 mm Detection, NPN NO, 10 → 30 V dc
Brand: ifm
SKU: IIS700
Availability: InStock

Part Number : IIS700

Availability: low stock

Detailed Description
Specifications
Downloads

The ifm electronic Inductive Sensor boasts advanced technology designed for industrial applications and factory automation. Featuring a precision-engineered threaded housing, this sensor ensures reliability and durability in even the toughest environments. With an increased sensing range of 15 mm and robust protection up to IP 69K, it is adept at functioning in extreme temperatures ranging from -40°C to 85°C. The product is equipped to handle shocks and vibrations while providing a yellow LED indication for easy monitoring.

Suitable for industrial, mobile, cooling and lubricating applications
High protection rating for the requirements of harsh industrial environments
Flexible use thanks to large operating temperature range
Safe detection due to large sensing range and low sensor tolerances
Reduced storage due to wide range of applications

Brand	ifm
Thread Size	M30
Sensor Technology	Inductive
Body Style	Threaded Barrel
Detection Range	15 mm
Output Function	NO
Digital Switching Output Type	NPN
Connection Type	Pre-Cabled
Cable Length	2m
Supply Voltage	10 → 30 V dc
Length	45mm
IP Rating	IP65, IP66, IP67, IP68, IP69K
Mounting Type	Flush
Switching Frequency	100 Hz
Shielding	Shielded
Series	IIS
Switching Current	100 mA

ifm IIS700, Inductive Threaded Barrel Proximity Sensor, M30, 15 mm Detection, NPN NO, 10 → 30 V dc
