ifm IM5019, Inductive Rectangular Proximity Sensor, 20 mm Detection, PNP NO/NC, 10 → 36 V dc

Name: ifm IM5019, Inductive Rectangular Proximity Sensor, 20 mm Detection, PNP NO/NC, 10 → 36 V dc
Brand: ifm
SKU: IM5019
Availability: OutOfStock

Part Number : IM5019

Availability: Sold out

Detailed Description
Specifications

The ifm electronic inductive sensor is designed to enhance precision in various industrial applications by delivering reliable performance across a range of operational conditions. Its robust rectangular housing is well-suited for challenging environments, providing an IP65 protection rating that ensures durability against dust and moisture. Featuring a sensing range of up to 20mm, this sensor's selectable output function allows for versatility in diverse use cases. The engineering behind its electrical design facilitates a PNP output, complementing advanced capabilities such as short-circuit and overload protection. With a notable operating temperature range, it thrives in both extreme cold and elevated heat, making it an ideal choice for manufacturers demanding resilience and accuracy.

Long sensing range for use in conveying
Output function normally open or normally closed programmable
Robust housing for use in harsh industrial environments
Clearly visible indication of the switching status

Brand	ifm
Sensor Technology	Inductive
Body Style	Rectangular
Detection Range	20 mm
Output Function	NO/NC
Digital Switching Output Type	PNP
Connection Type	Screw Terminal
Supply Voltage	10 → 36 V dc
IP Rating	IP65
Length	40mm
Mounting Type	Non-Flush
Series	IM5
Switching Frequency	300 Hz
Shielding	Unshielded
Switching Current	250 mA
