ifm IW5051, Inductive Block Proximity Sensor, 5 mm Detection, PNP NO, 10 → 36 V dc

Client Protection

Dedicated Support

Client Protection

Dedicated Support

ifm IW5051, Inductive Block Proximity Sensor, 5 mm Detection, PNP NO, 10 → 36 V dc

Name: ifm IW5051, Inductive Block Proximity Sensor, 5 mm Detection, PNP NO, 10 → 36 V dc
Brand: ifm
SKU: IW5051
Availability: OutOfStock

Part Number : IW5051

Availability: Sold out

Detailed Description
Specifications

Inductive proximity switch, 60 x 36 x 10 mm

Plastic case
Switching distance 5 mm (b), embeddable
N/O output function
2 m PVC cable

Block Style

Flush mounting, embeddable sensors with IP67 protection and an operating temperature range of -25 to +75°C. All have short circuit and reverse polarity protection and provide an LED indication of the on/off status.

Brand	ifm
Sensor Technology	Inductive
Body Style	Block
Detection Range	5 mm
Digital Switching Output Type	PNP
Output Function	NO
Connection Type	Pre-Cabled
Cable Length	2m
Supply Voltage	10 → 36 V dc
Length	60mm
IP Rating	IP67
Mounting Type	Flush
Housing Material	PBT
Width	36mm
Maximum DC Voltage	36V
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+80°C
Depth	10mm
Short Circuit Overload Protection	Yes
Switching Frequency	400 Hz
Reverse Polarity Protection	Yes

ifm IW5051, Inductive Block Proximity Sensor, 5 mm Detection, PNP NO, 10 → 36 V dc

ifm IW5051, Inductive Block Proximity Sensor, 5 mm Detection, PNP NO, 10 → 36 V dc

Inductive proximity switch, 60 x 36 x 10 mm
