ifm IW5058, Inductive Block Proximity Sensor, 8 mm Detection, PNP NO, 10 → 36 V dc

Name: ifm IW5058, Inductive Block Proximity Sensor, 8 mm Detection, PNP NO, 10 → 36 V dc
Brand: ifm
SKU: IW5058
Availability: OutOfStock

Part Number : IW5058

Availability: Sold out

Detailed Description
Specifications

Rectangular Inductive Proximity Sensor

Features and benefits

Very long sensing range

Easy setting of the sensing range via potentiometer

Large active sensor face

Output function normally open / normally closed programmable

Robust housing for use in harsh industrial environments

Brand	ifm
Sensor Technology	Inductive
Body Style	Block
Detection Range	8 mm
Digital Switching Output Type	PNP
Output Function	NO
Cable Length	2m
Connection Type	Pre-Cabled
Supply Voltage	10 → 36 V dc
IP Rating	IP67
Length	60mm
Mounting Type	Non-Flush
Width	36mm
Housing Material	PBT
Maximum DC Voltage	36V
Minimum Operating Temperature	-25°C
Short Circuit Overload Protection	Yes
Switching Current	250 mA
Depth	10mm
Reverse Polarity Protection	Yes
Maximum Switching Frequency	300Hz
