Mitutoyo 111-116 Spline Micrometer 25-50mm, 3mm Measuring Face
This Spline Micrometer makes it easy for you to measure grooves and shaped parts.
It offers you the following benefits:
- Stepped measuring surfaces.
- Suitable for measuring grooves, splined shafts, recesses, shaped parts, etc.
- Specifications
- Features
- Downloads
Accuracy | +/-3 µm |
Analog/Digital | Analog |
Delivered | Including box, setting standard |
Flatness | 0.3 µm |
Graduation | 0.01 mm |
Inch-Metric | Metric |
Mass (main unit) | 305 g |
Measuring spindle | With spindle lock, ƒ ̧6.35 mm, spindle pitch 0.5 mm |
Measuring surfaces | Carbide-tipped, micro-lap finish, stepped |
Parallelism | (2+L/100) 1/4m, L = max. range (mm) |
Range | 25 - 50 mm |
This Spline Micrometer makes it easy for you to measure grooves and shaped parts.
It offers you the following benefits:
- Stepped measuring surfaces.
- Suitable for measuring grooves, splined shafts, recesses, shaped parts, etc.
