Mitutoyo 143-109 | Caliper Jaw Micrometer | 200 to 225 mm, 0.01 mm
Part Number : 143-109
The Mitutoyo 143-109 is an analogue caliper jaw micrometer for 200 to 225 mm, graduated in 0.01 mm and ±11 µm accuracy, made for measuring where access is difficult. Constant measuring force on the 143-109 comes from its ratchet stop. The table below sets out the full 143-109 specification.
- 200 to 225 mm range
- Carbide-tipped, micro-lap finished faces; flatness 0.3 µm on the 143-109
- Ø8 mm spindle, 0.5 mm pitch, on the 143-109
- Satin chrome Ø18 mm thimble and sleeve; 690 g
- Delivered with box, setting standard, key on the 143-109
Free UAE shipping available
For pricing, please contact our experts.
