Mitutoyo 169-103 Disc Micrometer, Non-Rotating Spindle 0-1", Full Faced, Disk=14.3mm
Part Number : 169-103
This Disc Micrometer has a non-rotating spindle and allows you measure a range of different materials.
It offers you the following benefits:
- It features a non-rotating spindle and disc-shaped measuring surfaces.
- Measuring the root tangent length of spur and helical gears
- Measurable range of gear pitch: 0,5-6 module
- It‘s suitable for measuring materials such as felt, rubber, cardboard and fabric.
