Mitutoyo 2050A | Dial Gauge | Lug Back | ISO Type | Series 2 | Graduation 0.01mm | Range 20mm
The Mitutoyo 2050A is a high-precision dial gauge from Series 2, designed for accurate linear measurements in industrial applications. It features a lug-back design, allowing for secure mounting on various setups. With a 20mm measuring range and 0.01mm graduations, it is ideal for applications requiring tight tolerance measurements. The gauge complies with ISO standards, ensuring compatibility with industry-standard holders and accessories. Its jeweled bearing movement provides smooth, durable operation, while the scratch-resistant crystal offers clear visibility and enhanced durability. The sealed frame design protects against dust, oil, and moisture, ensuring reliable performance in harsh environments.

Free UAE shipping available
- Specifications
- Features
- Downloads
Contact point | Carbide tipped, thread: M 2.5 x 0.45 mm |
Dial Reading | +/-0.0-100.0 |
Digital/Analog | Analog |
Graduation | 0.01 mm |
Hysteresis | 5 µm |
Inch-Metric | Metric |
Mass (main unit) | 152 g |
Measuring Force | 0.4 - 2.5 N |
Measuring range | 25 µm |
Range | 30 mm |
Repeatability | 3.0 µm |
Series | 2 |
Stem Dia | 8.0 mm |
Type | Dial Gauge |
- Graduation: 0.01 mm for precise measurements
- Range: 20 mm measuring capacity for versatile applications
- Lug Back Design: Allows secure mounting on various setups
- ISO Compliant: Ensures compatibility with industry-standard holders and accessories
- Jeweled Bearing & Sealed Frame: Smooth operation with protection against dust, oil, and moisture for durability in harsh environments
