Mitutoyo 2110A-10 | Dial Gauge | Lug Back | ISO Type | Series 2 | Jewelled Bearing | Graduation 0.001 mm | Range 1 mm
The Mitutoyo 2110A-10 Dial Gauge is a high-precision measuring instrument designed for accurate linear measurements. It features a 1 mm measuring range with a 0.001 mm graduation, allowing for extremely fine readings. The gauge is equipped with a lug back for secure and stable mounting in various setups. It incorporates jewelled bearings, ensuring smooth operation and long-term durability. As part of Mitutoyo’s Series 2, it offers consistent performance and reliability. ISO type compliance guarantees adherence to international standards for precision measurements.

Free UAE shipping available
- Specifications
- Features
- Downloads
Analog/Digital | Analog |
Contact point | Carbide tipped |
Dial Reading | +/-0.0 - 100.0 |
Graduation | 0.001 mm |
Hysteresis | 2 µm |
Inch-Metric | Metric |
Measuring Force | 0.4 - 1.8 N |
Measuring range | 5 µm |
Range | 1 mm |
Repeatability | 1.0 µm |
Series | 2 |
Stem Dia | 8.0 mm |
Thread type | M 2.5 x 0.45 mm |
Type | Dial Gauge |
Type | EN ISO Standard |
Weight | 149 g |
- Measurement Range: 0 – 1 mm
- Graduation: Ultra-fine 0.001 mm for high-precision measurements
- Back Type: Lug back for secure and stable mounting
- Bearing Type: Jewelled bearings for smooth, long-lasting performance
- Series: Part of Mitutoyo’s highly reliable Series 2
- Compliance: ISO type, ensuring consistency with international precision standards
