Mitutoyo 2110S-10 | High Resolution Dial Indicator | 1 mm, 0.001 mm, Jewelled
With 1 mm of plunger travel and 0.001 mm graduations, the 2110S-10 from Mitutoyo is a high resolution dial indicator. It is intended for comparison measurement, with a 0-100 dial.
- Dial reading 0-100; measuring force 1.5 N or less
- Jewelled movement for low friction, shockproof construction and water-resistant design (2110S-10)
- O-ring sealing on the 2110S-10 against water and oil
- Carbide contact point fitted to the 2110S-10
- 2110S-10 stem and plunger made of quench-hardened stainless steel
- Tool-free left or right fitting of clamp and optional lifting lever (2110S-10)
- Specifications
- Features
- Downloads
| Part Number | 2110S-10 |
| Brand | Mitutoyo |
| Product Type | High Resolution Dial Indicator |
| Range | 1 mm (0.039 in) |
| Graduation | 0.001 mm |
| Dial Reading | 0-100 |
| Measuring Force | 1.5 N or less |
| Contact Point | Carbide tipped |
| Accuracy | ±5 |
| Bearing | Jewelled |
The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools.
• Secure adhesion between the bezel and crystal as well as the use of an O-ring prevents water or oil penetration.
• The plunger is made of high-strength quench hardened stainless steel which resists arduous use.
• A carbide contact point is used.
• A special alloy is used for the sector gears to provide improved wear resistance.
• The indicator uses jewelled bearings, providing excellent indication sensitivity and durability.
• Application of a hard coating on the surface of the crystal makes it highly resistant to scratching and chemical attack.
