Mitutoyo 2900SB-72 | Dial Indicator | Lug Back | One Revolution | Series 2 | One Revolution | Graduation 0.001mm | Range 0.08 mm
The Mitutoyo 2900SB-72 is a Series 2 dial indicator featuring a lug-back design for secure mounting. It offers a 0–0.08 mm measuring range with 0.001 mm graduations, ensuring precise measurements. The one-revolution dial eliminates the need to count multiple rotations, preventing reading errors. Designed to meet ISO/JIS standards, it ensures compatibility with global equipment. The shockproof and waterproof construction enhances durability in demanding environments. This model is ideal for applications requiring accurate linear measurements and reliable performance.

Free UAE shipping available
- Specifications
- Features
- Downloads
Analog/Digital | Analog |
Contact point | Carbide tipped |
Functions | ISO type |
Graduation | 0.001 mm |
Hysteresis | 2 µm |
Inch-Metric | Metric |
Measuring range | 3 µm |
Range | 0.08 mm |
Repeatability | 1 µm |
Series | 2 |
Stem Dia | 8 mm |
Stroke | Plunger: 4.5 mm |
Thread type | M 2.5 x 0.45 mm |
Type | Dial Indicator |
Weight | 140 g |
- Precision Measurement: 0.001mm graduations with a 0.08mm range for highly accurate measurements.
- One-Revolution Dial: Provides the full scale measurement in a single rotation, eliminating the need to count multiple rotations.
- Lug Back Design: Ensures secure and stable mounting for easy setup in various testing conditions.
- ISO/JIS Compliance: Built to meet international standards, ensuring compatibility with global systems.
- Shockproof & Waterproof: Designed for durability, even in harsh environments, offering long-term reliability.
- Reliable Performance: Ideal for high-precision applications that require consistent, repeatable measurements.
