Mitutoyo 2905S-10 High Resolution Reverse Reading Dial Indicator Range 0.05, Graduation 0.0001 inch

Name: Mitutoyo 2905S-10 High Resolution Reverse Reading Dial Indicator Range 0.05, Graduation 0.0001 inch
Brand: Mitutoyo
SKU: 2905S-10
Availability: InStock

Part Number : 2905S-10

A Mitutoyo shockproof, multi-revolution dial indicator with a reverse-graduated scale suited to general measurement applications in the reverse direction requiring high sensitivity. The jewelled movement provides lowest friction and stiction for smooth and precise operation.

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Accuracy	+/-.0001 inch
Brand	Mitutoyo
Data Output	No
Dial Reading	10-0
Display Type	Non-digital
Graduations	.0001 inch
Measuring Force	2.0N or less
Measuring Units	Inch
Range	.05 inch (.01)
SKU	2905S-10
Type	Plunger

The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools.
Secured adhesion between the outer frame and crystal as well as the use of an O-ring ensure countermeasures against water and oil permeation via the front face.
The stem spindle is made of high-strength quench-hardened stainless steel which resists strenuous use.
A carbide contact point is used.
The grand gear uses stainless steel that is resistant to wear and deformation.
Application of a hard coating on the surface of the crystal makes the gauge highly scratch- and chemical-resistant

Mitutoyo 2905S-10 High Resolution Reverse Reading Dial Indicator Range 0.05, Graduation 0.0001 inch

DOWNLOAD CATALOG
