Mitutoyo 2937S-10 | Dial Indicator | Graducation 0.0001 inch | Range 0.02 inch | Accuracy ±.0001 inch
The Mitutoyo 2937S-10 Dial Indicator offers high precision with a graduation of 0.0001 inch and a range of 0.02 inch. It provides ±0.0001 inch accuracy, ensuring extremely fine and reliable measurements. Designed for precise measurements in tight tolerance applications, it is ideal for quality control and precision inspection in manufacturing. The dial indicator's durable construction ensures long-lasting performance even in demanding environments. Perfect for industries that require detailed, accurate measurements of small parts and components.
- Specifications
- Features
- Downloads
| Accuracy | +/-0.0001 inch |
| Dial Reading | 0-4-0 |
| Graduation | 0.0001 inch |
| Measuring Force | 2.0N or less |
| Range | 0.02 inch |
| Type | Dial Indicator |
- Improved immunity to shock from abrupt spindle retraction brought on by high impact is provided by a special shock-proof mechanism.
- For durability and scratch resistance, the crystal is hard coated.
- It weighs around 40% less than a traditional dial indication.
- enhanced resistance to dust and water, two common pollutants found on shop floors.
- When clamping along the stem, spindle movement won't be impeded or jammed since the spindle bushing is offset from the stem.
- For quick and simple tolerance judgment (GO/±NG), a pair of limit hands are provided.
