Mitutoyo 2959A | Dial Gauge | Lug Back | ISO Type | Series 2 | One Revolution | Graduation 0.01mm | Range 1.6 mm
The Mitutoyo 2959A is a Series 2 dial indicator featuring a lug-back design for secure mounting. It offers a 0–1.6 mm measuring range with 0.01 mm graduations, ensuring precise measurements. The one-revolution dial simplifies readings by eliminating the need to count multiple rotations. Designed to meet ISO/JIS standards, it ensures compatibility with global equipment. The shockproof construction enhances durability in demanding environments. This model is ideal for applications requiring accurate linear measurements and reliable performance.

Free UAE shipping available
- Specifications
- Features
- Downloads
Analog/Digital | Analog |
Contact point | Carbide tipped |
Dial Reading | 80.0-0.0-80.0 |
Graduation | 0.01 mm |
Hysteresis | 4 µm |
Inch-Metric | Metric |
Measuring Force | 0.4 - 1.4 N |
Measuring range | 9 µm |
Range | 1.6 mm |
Repeatability | 3.0 µm |
Series | 2 |
Stem Dia | 8.0 mm |
Stroke | Plunger: 5 mm |
Thread type | M 2.5 x 0.45 mm |
Type | Dial Gauge |
Type | EN ISO Standard |
Weight | 145 g |
- Precision Measurement: 0.01mm graduations with a 1.6mm range for accurate and detailed readings.
- One-Revolution Dial: The Entire measuring range is displayed in a single rotation, minimizing reading errors.
- Lug Back Design: Ensures secure mounting on test fixtures and stands for stable measurements.
- ISO/JIS Compliance: Meets international standards, allowing for easy integration into global systems.
- Shockproof Build: Durable construction resists impacts and vibrations in tough workshop environments.
- Reliable Performance: Designed for consistent, high-accuracy results in industrial and inspection settings.
