Name: Mitutoyo 523-132 Dial Snap Meter 1-2"
Brand: Mitutoyo
SKU: 523-132
Availability: OutOfStock

Part Number : 523-132

This is a Snap Gauge with integrated dial comparator. It offers you the following benefits:

It is ideal for rapidly inspecting workpieces, especially cylindrical, in batch or mass production situations.
It can be set with external length standards such as block gauges.
Easy-to-operate retracting button

Availability: Sold out

Free UAE shipping available

Analog/Digital	Analog
Delivered	Including box, workpiece rest
Flatness	0.000012"
Inch-Metric	Inch
Mass (main unit)	840 g
Measuring spindle	ƒ ̧10.8 mm
Measuring surfaces	Carbide-tipped, micro-lap finish ƒ ̧10.8 mm
Parallelism	0.000024"
Range	1 - 2"

This is a Snap Gauge with integrated dial comparator. It offers you the following benefits:

It is ideal for rapidly inspecting workpieces, especially cylindrical, in batch or mass production situations.
It can be set with external length standards such as block gauges.
Easy-to-operate retracting button
