Mitutoyo 7305 | Dial Thickness Gauge | 0–20 mm, 0.01 mm, Standard
Part Number : 7305
This standard flat-contact dial indicator thickness gauge (7305) measures 0–20 mm, graduated in 0.01 mm. The flat contact points of the 7305 are meant for thin materials such as film or paper. Mitutoyo builds this gauge family in standard, lens thickness, groove depth, tube thickness and deep-throat forms; the 7305 is the standard type.
- Range 0–20 mm, graduation 0.01 mm
- Dial indicator no. 2050SB (7305)
- Main unit mass 220 g (7305)
- Throat depth 30 mm (7305)
- Contact parallelism: 5 µm (7305)
- Contact point thread M2.5 x 0.45 mm (7305)
- Front face sealed by one-piece bezel and crystal against water and oil (7305)
Free UAE shipping available
For pricing, please contact our experts.
