Omron A22NE-M-P102-N-B, A22NE Series Turn to Reset Emergency Stop Push Button, Surface Mount, 22mm Cutout, 1 NO + 1 NC, IP65

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron A22NE-M-P102-N-B, A22NE Series Turn to Reset Emergency Stop Push Button, Surface Mount, 22mm Cutout, 1 NO + 1 NC, IP65

Name: Omron A22NE-M-P102-N-B, A22NE Series Turn to Reset Emergency Stop Push Button, Surface Mount, 22mm Cutout, 1 NO + 1 NC, IP65
Brand: OMRON
SKU: A22NE-M-P102-N-B
Availability: OutOfStock

Part Number : A22NE-M-P102-N-B

Availability: Sold out

Detailed Description
Specifications
Downloads

Omron A22NE Series Emergency Stop Push Button, 12V Voltage Rating, 22mm Cutout Diameter - A22NE-M-P102-N-B

This emergency stop push button is specifically designed for effective safety control in various industrial applications. Featuring a robust round push button shape, it is intended for surface mounting and requires a cutout diameter of 22mm. The device is equipped with both normally open (NO) and normally closed (NC) safety contacts, allowing for versatility in emergency situations. Designed with an IP65 rating, this product ensures protection against dust and water, making it reliable for challenging environments.

Features & Benefits

• Designed for surface mounting to simplify installation
• Turn to reset functionality enhances usability in emergencies
• 12V AC/DC voltage rating accommodates various electrical systems
• IP65 rating ensures durability in harsh environments
• Equipped with safety contacts to enhance operational safety
• Round push button shape allows for easy access and operation

Applications

• Used with machinery requiring immediate shutdown capabilities
• Suitable for control panels in industrial automation systems
• Utilised in emergency stop circuits for mechanical devices
• Ideal for assembly lines needing quick response solutions

What is the purpose of the safety contacts in this product?

The safety contacts provide a dual-function mechanism, enabling immediate disconnection of power when activated, which is essential for ensuring operator safety during emergencies.

How does the IP65 rating benefit the push button in an industrial setting?

The IP65 rating protects the device against dust ingress and water exposure, ensuring reliable operation even in environments where moisture and contaminants are present.

What type of mounting is required for this push button?

This push button is designed for surface mounting, necessitating a cutout of 22mm for proper installation, making it versatile across different equipment types.

What electrical systems can this product support?

The push button operates on a voltage rating of 12V AC/DC, making it compatible with a variety of electrical systems commonly used in automation and industrial machinery.

Brand	Omron
Mounting Type	Surface Mount
Cutout Diameter	22mm
Contact Configuration	1 NO + 1 NC
Push Button Actuation	Turn to Reset
Voltage Rating	12V ac/dc
Illuminated	No
Series	A22NE
IP Rating	IP65
Colour	Red
Push Button Shape	Round
Safety Contacts	2
Push Button Diameter	40mm
