Omron A6SN-1101, 1 Way Surface Mount DIP Switch SPST, Flat Actuator, IP40

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron A6SN-1101, 1 Way Surface Mount DIP Switch SPST, Flat Actuator, IP40

Name: Omron A6SN-1101, 1 Way Surface Mount DIP Switch SPST, Flat Actuator, IP40
Brand: General Tech Services LLC
SKU: A6SN-1101
Availability: OutOfStock

Part Number : A6SN-1101

Availability: Sold out

Detailed Description
Specifications

The Omron makes this surface mounted, slide DIP switch which is rated for 25 Vdc at 25 mA. have high contact reliability. With this device, washing is possible and has insulation resistance of 100 MΩ minimum (at 100 VDC with insulation tester).

Contact resistance (initial value) 200 mΩ max
Durability electrical 1,000 operations min

Brand	Omron
Number of Positions	1
Mounting Type	Surface Mount
Contact Configuration	SPST
Contact Material	Gold
Actuator Type	Flat
Contact Current Rating	25 mA at 25 Vdc VA
IP Rating	IP40
