OMRON E3S-R32 | Retroreflective Photoelectric Sensor | 100 mm to 300 mm, PNP, Pre-Wired Cable
The OMRON E3S-R32 is a block-style retroreflective photoelectric sensor with a 100 mm to 300 mm detection range. It provides PNP output and a pre-wired cable. The PBT housing is rated IP67 for operation from 0°C to +40°C. Its infrared light source gives a response time of 1 ms.
- Maximum DC voltage: 30V
- Maximum current: 100 mA
- Series: OMRON E3S
- Detection range: 100 mm to 300 mm
- Output: PNP
- Connection: pre-wired cable
- Detailed Description
- Specifications
- Downloads
E3S-R1 and R3 Series Clear Object Sensors
Light On/dark On operation selectable
Retroreflective, horizontal mount
Load short circuit and mutual interference protection
Response time: 1ms (ON or OFF)
Two-turn sensitivity adjustment
Connection: Pre-wired cable included
E39-R1 reflector included
IP67 rated

| Brand | Omron |
| Series | E3S |
| Detection Type | Retroreflective |
| Detection Range | 100 mm → 300 mm (3.94 to 11.8 in) |
| Sensor Style | Block |
| Output Type | PNP |
| Electrical Connection | Pre-Wired Cable |
| Light Source | Infrared |
| Response Time | 1 ms |
| Maximum DC Voltage | 30V |
| IP Rating | IP67 |
| Maximum Current | 100 mA |
| Minimum Operating Temperature | 0 °C (32 °F) |
| Housing Material | PBT |
| Maximum Operating Temperature | +40 °C (104 °F) |
