Omron E5CB-R1TC 100-240 VAC, E5CB Panel Mount PID Temperature Controller, 48 x 48mm 1 Input, 1 Output Relay, 100 → 240 V ac Supply Voltage

Name: Omron E5CB-R1TC 100-240 VAC, E5CB Panel Mount PID Temperature Controller, 48 x 48mm 1 Input, 1 Output Relay, 100 → 240 V ac Supply Voltage
Brand: OMRON
SKU: E5CB-R1TC 100-240 VAC
Availability: OutOfStock

Part Number : E5CB-R1TC 100-240 VAC

Temp. controller, LITE, 1/16DIN (48 x 48mm), relay output, ON/OFF or PID Control, Thermocouple input, 1 Alarm Rel., 100-240 VAC

Availability: Sold out

Detailed Description
Specifications
Features

Omron E5CB Series Pid Temperature Controller, LED Display, IP00/ IP20/ IP66 - E5CB-R1TC AC100-240

This temperature controller by Omron is designed for heater control with high control performance at a cost-effective price. Featuring a large character LED display, it offers enhanced visibility with a character height of approximately 16 mm. With simple setup requiring fewer than 20 parameters, this controller provides faster sampling and loop update at 250 ms interval. It is panel-mounted and comes with a relay output, suitable for various applications.

Features & Benefits

• Large character LED display
• Simple setup with fewer parameters
• Fast sampling and loop update at 250 ms
• Reliable relay output for control
• Panel-mounted for easy installation
• Enhanced visibility with a character height of 16 mm

Applications

• Temperature control in industrial processes
• Heater control in manufacturing units
• Monitoring and regulating temperature in electronic equipment

Can it be used for industrial applications requiring precise temperature control?

Yes, the Omron temperature controller is ideal for precise temperature control in various industrial applications.

Will it work well for controlling heaters in electronic devices?

Yes, the controller is designed specifically for heater control in electronic devices, offering high performance at a low cost.

Is the LED display easily readable in different lighting conditions?

The LED display with a character height of 16 mm ensures easy readability in various lighting environments.

Brand	Omron
Output Type	Relay
Supply Voltage	100 → 240 V ac
Size	48 x 48mm
Number of Inputs	1
Number of Outputs	1
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+55°C
Temperature Range	-10 → +55 °C
Control Type	ON/OFF, PID, 2-PID Controller
Communication Module Available	Yes
Display Type	LED
IP Rating	IP00, IP20, IP66
Mounting Type	Panel Mount
Series	E5CB
Range	Omron E5CB
Input Type	Thermocouple
Additional Functionality	ON/OFF
Termination Type	Screw terminal block
Panel Depth	60mm

Temp. controller, LITE, 1/16DIN (48 x 48mm), relay output, ON/OFF or PID Control, Thermocouple input, 1 Alarm Rel., 100-240 VAC
