Omron E5CC-CX3A5M-000, E5CC Panel Mount PID Temperature Controller, 48 x 48mm, 1 Output Linear, Analogue, 4-20 mA, 100 → 240 V ac Supply

Name: Omron E5CC-CX3A5M-000, E5CC Panel Mount PID Temperature Controller, 48 x 48mm, 1 Output Linear, Analogue, 4-20 mA, 100 → 240 V ac Supply
Brand: OMRON
SKU: E5CC-CX3A5M-000
Availability: OutOfStock

Part Number : E5CC-CX3A5M-000

Temperature controller, 1/16 DIN (48x48 mm), 0/4-20 mA current output, 3 AUX, 100-240 VAC

Availability: Sold out

Detailed Description
Specifications
Features

Omron E5CC Series PID Temperature Controller, 100 to 240V AC Supply Voltage, -200 to +2300°C Temperature Range - E5CC-CX3A5M-000

This PID temperature controller is designed for precise and effective temperature management across a variety of industrial applications. With an extensive temperature range, it ensures performance in different environments, meeting the requirements of automation, electronics, and mechanical industries.

Features & Benefits

• Supports ON/OFF and PID control for versatile temperature regulation
• Universal input accommodates various temperature sensors
• Linear analogue output facilitates seamless data integration
• IP66 rating offers protection against dust and moisture
• Compact design is suitable for panel mount installations
• Operates within a temperature range of -10 to +55°C

Applications

• Suitable for process control in manufacturing settings
• Used with platinum resistance thermometers for accuracy
• Ideal for detailed temperature monitoring in laboratories
• Essential in HV AC systems for maintaining conditions
• Aids automation processes in the food and chemical sectors

What temperature sensors are compatible with this device?

It accommodates various sensors, including thermocouples and platinum resistance thermometers.

How is the installation process for panel mounting?

Installation is straightforward, involving secure connections to the screw terminal block.

Can this controller manage extreme temperature variations?

Yes, it operates effectively within a temperature range of -200 to +2300°C.

What type of output signal does it provide for data transmission?

It features a 4-20 mA linear analogue output for efficient data communication.

Are there any specific maintenance requirements for this controller?

Regular checks of connections and display functionality are recommended for optimal operation.

Omron - E5GC, E5CC, E5EC, E5AC, E5DC, E5CN & E5CB Ranges

Brand	Omron
Output Type	Linear, Analogue, 4-20 mA
Supply Voltage	100 → 240 V ac
Size	48 x 48mm
Number of Outputs	1
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+55°C
Control Type	ON/OFF, PID, 2-PID Controller
Mounting Type	Panel Mount
Series	E5CC
Input Type	Universal, Platinum Resistance Thermometer, PT100, Thermocouple, Analogue
Range	+10 → +70 °C, +115 → +165 °C, +140 → +260 °C, +60 → +120 °C
Panel Depth	60mm
Termination Type	Screw terminal block

Temperature controller, 1/16 DIN (48x48 mm), 0/4-20 mA current output, 3 AUX, 100-240 VAC
